Shanghai Lei Magnetic Automatic Titrator ZDJ-5B(Single pipe )_Potentiometric Titrator

【Main features】

7Cun color touch screen, navigation operation； Display test methods, titration curves and measurement results in real time ；

Includes a set of built-in buret pipes, which can expand the second set of buret pipes (optional, external)；

Adopt the integrated design of valve buret pipes, directly replace them to effectively avoid interference, and support 10 mL、20mL Various burets；

Supports pretitation (dynamic titration), blank titration (equal titration), preset endpoint titration, constant titration, manual titration and other titration modes, and supports self-built dedicated modes；

Supports various titration methods such as acid-base titration, redox titration, precipitation titration, complex titration, and non-water titration.； Supports the establishment, editing, copying and review of titration methods ； support pH Measurement function；

Supports method management, can store 100 sets of titration methods；

Supports data management and can store 200 sets of compliant GLP Standardized titration results； Supports data statistics function, allowing users to count, review, analyze and compare titration results. ；

Supporting /Two operating languages in English； Support user management function ；

Supports power outage protection function and self-diagnosis function；

support USB、RS232 connect PC， Two-way communication, support U Plug and play on the disk, randomly give away special titration software；

Automatic sampler can be directly connected to achieve automatic measurement of batch samples.

【Technical parameters]

model Technical parameters			ZDJ-5B
drop Certainly Pack Set	Capacity Titration unit	Titration analysis repetition	0.2%
		Allowable Error of Titration Capacity	10ml Burner: ±0.025ml；20ml Burner: ±0.035ml
		Burner resolution	10ml Burner: 1 /10000；20ml Burner: 2 /10000
		Burner infusion or Rehydration speed	(55±10)s（ When the buret is full)
Test quantity Pack Set	Potentiometric titration module	Measurement range	（-1999.0～1999.0）mV，（0.00～14.00)pH
		Resolution	0.1mV，0.01pH
		Basic error	pH：±0.01pH±1Word mV：±0.03%FS
		stability	(±0.3mV±1Word )/3h
	Temperature compensation	Measurement range	（-5.0～105.0）℃
		Resolution	0.1℃
		Basic error	±0.3℃
power supply			AC(220±22)V； frequency (50±1)Hz
size (mm)，weight (kg)			340×400×400，10

【Main functions】

model Main functions		ZDJ-5B
Titration unit	Built-in buret line	●
	Extended external buret pipes	●
	Integrated burette	●
	10ml/20 ml Optional	●
Signal unit	Potentiometric titration module	●
	Conductance Titration Module	/
	Permanent stop titration module	/
	Photometric titration module	/
	Temperature titration module	/
Display		7Color touch screen
Computer software control		●
Titration mode	Pretitration (dynamic titration)	●
	Preset end titration	●
	Constant titration	●
	Blank titration	●
	Manual titration	●
	Custom titration	●
Titration method		100
Store data		200
Data interface	RS-232	●
Data interface	USB	●
Automatic sampler		●
U Drive hardware upgrade		●

ZDJ-5B Automatic titrator

Serial number

Name and specifications

quantity

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

26

27

1

2

3

ZDJ－5B Automatic titrator

232-01Reference electrode

213-01Platinum electrode

216-01Silver electrode

217-01Reference electrode

231-01type pH Glass electrode

T-818-B-6 Type temperature electrode

Drop tube and infusion tube (Fluoroplastic )(SC5.462.023)

Solution cup (SC8.219.010)

Solution cup (SC8.463.001)

Rod tool (SC8.227.126)

Burner valve device 10 ml(SC5.461.044)

Stir beads (small)

Electrode frame device (SC5.108.022)

Infusion tube (Fluoroplastic ) Φ3.2×0.5(import )

Pipe connection nut GS-14A,B(import )

Plastic liquid storage bottle (500ml)

fuse Φ5×20(3A)

International general power cord

TP-16 Serial printer connection

USB Communication connection

RS232 Communication line

7.0Resistive pen with tail buckle (touch pen)

pH Buffer reagent ( pH4.01/6.86/9.18）

ZDJ-5B Product instruction manual and application examples

Product Certificate

Lei Magnetic Automatic Titration Software

The following are the optional parts for users

Auxiliary titration device

Burner valve device 20 ml(SC5.461.044)

On the mixer (5.203.002)

1tower

1branch

2root

3Only

1indivual

1set

3Only

1set

2root

3 each

1Only

2Only

1root

1branch

1set

1 book each

1share

1plate

1tower

1set

1indivual

Product Brochure

Packing List

Product Sheet
