Dark Field

✓

Lighting

Transmission Cole Illuminator

LED lamp

·           No Keller

Focus

Focusing device

Stage focus

✓

Handle stroke

·           15mm

characteristic

Coarse adjustment limit valve
  Flexible adjustment of coarse adjustment knob

Objective lens converter

Manual

Standard type

Built-in 4 holes

Stage

Mechanical

Right (left) manual control mechanical stage

·           built-in

·           X:76mm,Y:30mm

Condensing mirror

Manual

Abe Concentrator

NA1.25/W.D.-(4X-100X)(built-in )

Lens cylinder

standard( FN20）>Binocular tube

✓

Lens inclination angle

·           30°

Pupil spacing adjustment

·           48-75mm

External dimensions

198(W)x258(D)x384(H)mm

weight

About 5.9 kg
