Measurement scale

Optometry, international standard sugar level  ( No temperature compensation  ),
International standard sugar content  ( Automatic temperature compensation  )

Measure readings

Optometry, international standard sugar level  ( No temperature compensation  ),
International standard sugar content  ( Automatic temperature compensation  ), Specific optical rotation, concentration, purity

Measurement range

Optical rotation
-89.99 to  +89.99°
International standard sugar content
-130.00 to  +130.00°Z

Minimum indicator value

Optical rotation 0.01 °
International standard sugar 0.01 °Z

Measure the exact value

Optical rotation
 Display value    ±0.01° ( -35.00 to  +35.00° )
 Related exact value is less than  ±0.2%
 ( -35.01° To -89.99 °, +35.01° to  +89.99° )
International standard sugar content
 Display value    ±0.03°Z ( -101.00 to  +101.00° )
 Related exact value is less than  ±0.2%
 ( -130.00 To -101.01 °Z, +101.01 to  +130.00°Z )
( Using standard quartz sheets to measure  )

International standard sugar temperature correction

18.0 To 30.0 °C

Wavelength measurement

589nm(D-line)

Display board

With background light LCD show

Power consumption

65VA

power supply

AC100V  To 240 V And 50 /60Hz

Accessories

100mm(5ml), 200mm(10ml) Optical tube (1 each )

Output

• Digital printer  DP-63, DP-AD ( Options Selected items  )
• RS-232C interface

Dimensions and weights

48.5×28.5×17.5Centimeters, 13.9 grams  (Parts-free weight )

Options

• Special configurations suitable for sugar production  A Type is temperature control type: Model 5296
• Special configurations suitable for sugar production  B Type is temperature compensation type: Model 5297
• Digital printer  DP-63 :  Model 3118
• Digital printer  DP-AD :  Model 3123
• Optical tube 100 mm long OT-100 (A): RE-72001
• Optical tube 200 mm long OT-200 (A): RE-72002
• Optical rotary tube with water bath jacket 100 mm : RE-72034
• Optical rotary tube with water bath jacket 200 mm : RE-72035
• Optical tube with water bath jacket 50 mm : RE-72036
• Optical rotary tube with water bath jacket, fitted sample funnel set 100 mm : RE-72033
• Optical rotary tube with water bath jacket, fitted sample funnel set 200 mm : RE-72032
• Quartz glass sheet 34 ° : RE-72045
• Quartz glass sheet 17 ° : RE-72044
• Quartz glass sheet 8 ° : RE-72043

Consumables /Component

• Glass plate for optical rotation tube :  RE-6712
• Optical tube rubber sleeve :  RE-6713
• Nuts for optical rotating tubes :  RE-6714
• Light source light bulb set :  RE-74806
• DP-RX Use printingPaper :  RE-8412
• DP-RX Print for long-term usePaper :  RE-8414
• DP-AD Use printingPaper :  RE-89403
• DP-AD Use ink cartridges :  RE-89402
