Usage overview:

It takes advantage of the natural convection phenomenon of hot air rising, slow air flow, low dust and no noise, and is suitable for drying, baking, molten wax, sterilization, etc.

Features:

● The inner liner is made of stainless steel, and the inner liner has a semi-circular arc transition, which is convenient for the cleaning of the studio.

● Natural convection circulation is adopted to avoid volatility of samples during the test.

● Adopt microcomputer with overtemperature deviation protection and digital display P.I.D Temperature controller with timing function, accurate and reliable temperature control.

● Independent temperature limit alarm system, the temperature exceeds the limit will be automatically interrupted, ensuring safe operation of the experiment without accidents. (Optional)

● Can be equipped with a printer or RS485 Interface, used to connect to a printer or computer, can record changes in temperature parameters. (Selection )

◆ Multi-segment programmable controller (optional)

● Multi-stage LCD programmable controller, multiple parameters are displayed on one screen, and menu-style operation interface can simplify complex test processes and truly realize automatic control and operation.

● Multi-stage temperature, circulating wind speed, time and heating rate can be set and programmed at the same time, and gradient control of temperature rise can be performed, and functions such as slow heating from the initial temperature in the box can be preset. Functions such as automatic power-on, standby and shutdown can also be preset.

● 7 segments and 63 steps can be preset, 9 steps per segment, and 1 time per segment ～9959 minutes at hour.

Technical parameters:

 Optional purchase: (Increase the delivery time of optional parts for 7 days )

Note: RS485/232、Choose one of two printers
