Features

★Industrial-grade color LCD display and touch screen operation.
★Eight-channel fiber optic measurement system, imported detector.
★Accurate center positioning function, accurate and reliable.
★Three linear vibrator functions and adjustable speed time.
★Unique way to open Cut-Off Judgment formula, lose what you lost.
★End point method, two-point method, dynamics, single /Dual wavelength test mode.
★Configure the suppression rate measurement module, dedicated to the food safety field.

Technical parameters

light source: DC12V 22W Imported tungsten halogen lamp
Optical path system: 8-channel vertical optical path system
Wavelength range: 400-800 nm
Filter: Standard 405 (Or 412 )、450、492、630nm,
Other wavelength options, can be loaded with 10 filters
Reading range: 0-4.000 Abs
Resolution: 0.001 Abs
Display error: ≤±0.01Abs
stability: ≤±0.003Abs
Repeatability: ≤0.3%
Vibrating plate function: 3-level vibrating plate speed, time adjustable 0-255 seconds
Display operation: 8-inch color LCD screen, video panel, display board information, touch screen operation
Workstation: Professional microplate reader software, which can store 100 sets of programs and 100,000 sample results, and provides rich calculation modes such as absorbance, threshold, linear equation, logarithmic equation, quadratic equation, cubic equation, exponential curve, power function, absorbance percentage-concentration logarithmic equation, 4-parameter equation, etc.
Power supply: Wide voltage design AC100-240V 50-60Hz
Net weight: approximately 11 Kg
Size: 433 mm(L)*320mm(W)*308mm(H)
