Main features:

● Improved double cathode stainless steel electrolytic separation cell, electrolytic nitrogen production, oxygen discharge is carried out simultaneously, and the electrolyte circulation is smooth.

● The electrolytic separation cell has a large electrolytic area, a low cell temperature, a large gas production, and a higher nitrogen purity.

● Unique anti-return device ensures that the instrument has no reflux phenomenon.

● It has the function of stabilizing and automatically closing the air circuit after power outage.

● Adopt advanced switching power supply to improve electrolytic separation efficiency.

Technical indicators:

● Nitrogen purity: ＞99.999％

● Output flow: 0 ~ 300mL/ min

● Output pressure: 0 ~ 0.5Mpa（ Factory setting 0.4 Mpa）

● power supply: AC220V±10％，50Hz±5％，80W

● Environmental conditions: Ambient humidity: 10 ~ 40℃；Relative humidity: ≤85％

● Instrument size: 320 mm×220mm×370mm

● Weight: 15 kg
