SCH-02 The automatic sample injector is an auxiliary device that supports continuous automatic measurement of multiple samples or measurement of reproducibility of a single sample result. It has the functions of sample positioning, cleaning, stirring, etc., and can be used as ZDJ-5B Type series automatic titrator, electrochemical leading multi-parameter analyzer, intelligent T The series of instruments are perfectly used to perform continuous measurement of multiple samples.

Main features

n  It adopts a double tower surface structure design, with a removable turntable, and is compatible with sample cups of different sizes by replacing the upper tower surface. Three specifications of sample disks are available, each of which is 32-digit 50 mL Sample disc, 24-digit 100 mL Sample disc, 18-bit 200 mL Sample tray

n  With sample positioning and cleaning functions

n  Supports stirring function, stirring up or stirring down can be optional

n  The instrument has self-test and fault tolerance functions

n  have USB、RS232 Dual interface, can be used with ZDJ-5B Type series automatic titrator, electrochemical leading multi-parameter analyzer, intelligent T Perfect use of series of instruments

n  support PUMP-1 Type diaphragm pump, PUMP-2 peristaltic pump used to measure the front and rear cleaning sensors and extract waste liquid in the solution cup

Technical parameters
