Unique product features:

1.Back brilliant LCD screen - makes the screen clearer and brighter, and provides rich measurement information

2.Convenient operation-no cumbersome menu, 6 buttons can easily complete all operations

3.Outstanding performance - The thermally insulated weighing sensor technology is used to prevent the impact of the temperature accuracy of the heating process

4.Standard RS232 Communication interface - convenient to connect printers, computers and other peripheral devices

Heating method:

MB23（ Infrared heating moisture meter) - suitable for sample measurement with high sugar content or other easily burnt

Technical parameters:
Range (g) 110
readability (g) 0.01
readability (>10g sample )(%) 0.1%
Repeatability (3g sample )(%) 0.3%
Repeatability (10g sample )(%) 0.2%
Minimum sample size (g) 0.5
Recommended sample quantity (g) 3~20
Scale size (mm)
 Diameter 90
Heating procedure standard
Ambient operating temperature (℃) 10℃-30℃
Two-way communication RS232

End point control timing, automatic
Heating temperature range (℃) 50℃To 160 ℃(5℃For a ladder )

Display content moisture %, solid %, weight, time, temperature
Heating time 1 ~60The minute step is 30 seconds, 60 ~90The minute step is 1 minute
External dimensions (Width ×high ×long )(mm) 165×127×280
net weight( kg） 2.1
Total weight ( kg） 4.15
Standard configuration of sample disk handle
Heating source: infrared heating

Consumables purchase:

Product name: Moisture measuring instrument sample aluminum foil tray |Moisturemeter sample aluminum disk

model: LB01

Dimensions: 90 diameter mm

Packaging: 50 pieces /box

Price: 200 yuan /Box (optional)

Purpose: Suitable for sample moisture measurement, hold samples for accurate measurement
