Product Introduction:

DJS The series of potentiostats are electrochemical testing instruments, which can be widely used in the research of electrode process dynamics, chemical power supply, electroplating, metal corrosion, electrochemical analysis and organic electrochemical synthesis.

Features:

Even digital display, light touch keyboard, high precision and good stability. Touch keyboard, large screen LED Even digital display can display constant potential and constant current at the same time using low drift and high-precision circuit system. The original imported high-power integrated circuit is equipped with overpower protection and automatic alarm functions. It has stable and reliable operation and external signal input impedance greater than 1 KΩ，Amplitude is not greater than 2 Vpp It has reference potential, working current, and slot voltage output.

Technical parameters:

1.Potential control range ±2V，±4V, Continuously adjustable

2.Constant potential load characteristics: not greater than 1 mV±1Word

3.Maximum output current 199.9 mA， Can be divided into seven steps, with minimum resolution of 1 nA

4.Switching rate: greater than 1 V/μS

5.Current control range: ±2μA～±200mA A total of seven tiers

6.Constant current load characteristics: ±1％（F·S）±1Word

7.The input impedance of the reference electrode is not less than 9th power of 10 Ω

8.Slot voltage range: ±20V

9.Ultra-low frequency step scanning, peak value adjustable 0 ～±1V

10.Power supply: AC 220V/50HZ

11.Appearance size: 320 ×240×90mm
