Product/Brand

Heavy Metal Analyzer
Shanghai Lei Magnetic Heavy Metal Analyzer SJB-802
Price:¥118000

WeChat

Brand:lei-ci
Model:SJB-802
Inventory Status:Spot promotion/please call for consultation
Contact:
Tel:+86 010-51660436
Email:dnyc_sales@163.com
Details Documentation Related

Product Description:

● 4.3Cun-high-bright color screen, menu-style operation, easy to use;

● Visual design:

a) Automatic calibration, automatic cleaning, operation process interface display;

b) Waiting time interface display of measurement, calibration, cleaning and other processes;

c) A prompt will be given when the sensitivity is not selected;

d) Displays measurement scanning curves for easy reading analysis;

● The anode dissolution voltammetry is used, and the detection limit is low, and the minimum can be as low as 0.1 ppb;

● Adopt a three-electrode detection system and a printed electrode system, and combine it with a stirring and stirring system to ensure the accuracy of detection;

● Fast detection speed, a single measurement can be completed within 5 minutes;

● Built-in rapid testing, standard testing, standard addition and other measurement modes. The detection method can be called directly to quickly test the model ● Three-step inspection, quick and convenient;

● Built-in detection methods of 10 ions of lead, cadmium, copper, arsenic, mercury, zinc, selenium, manganese, nickel, and chromium, directly call; Easy to expand other heavy metal ion detection methods through software upgrade ;

● conform to GLP Specification, supports data storage, deletion and reference, with a maximum storage capacity of 2,000 groups. Support data output and save SD Card;

● Has standard USB Communication interface and REX Data acquisition software, support and PC Connection and data output;

● IP65 Protection level, multiple power supply methods, supports universal AC power adapter with commonly used mobile phone chargers, supports 4 No. 5 rechargeable NiMH batteries, USB terminal power supply, external mobile power supply, USB Car power supply; Suitable for mobile measurement ;

● The consumables are independently developed, and the supporting reagents meet no less than 50 measurements, with obvious cost advantages.



Technical parameters:

Electrode system

model

Technical parameters

SJB-802







Three electrodes

system





Measurement range

Zinc, lead, cadmium, copper, arsenic: (0 ~1000)μg/L; Scalable to 10 mg/L;

Mercury, nickel, chromium: (0 ~100)μg/L; Scalable to 1 mg/L;

Selenium, Manganese: (0 ~500)μg/L; Scalable to 5 mg/L

Polarization voltage accuracy

No more than ±1%or ±5mV(≤0.5V and ≥-0.5V)

Detection limit

Lead, cadmium, arsenic, copper: ≤0.5μg/L;

Zinc, selenium, manganese, nickel, chromium: ≤1μg/L;

mercury: ≤0.1μg/L

Display error

Lead, cadmium, arsenic, copper, zinc, selenium, manganese, nickel, chromium: no more than ±5%or ±5.0μg/L(≤100μg/L);

Mercury: No more than ±5%or ±3.0μg/L(≤60μg/L)

Repeatability

≤3%

The deviation of the influence of power supply voltage changes on concentration measurement value

No more than ±10%

The deviation of influence of ambient temperature changes on polarization voltage

No more than ±0.5mV/℃



Printed electrodes

system





Measurement range

Lead, cadmium, arsenic: (0 ~200)μg/L;

Mercury: (0 ~100)μg/L

Polarization voltage accuracy

No more than ±1%or ±5mV(≤0.5V and ≥-0.5V)

Detection limit

Lead, cadmium: ≤5μg/L;

arsenic: ≤10μg/L;

mercury: ≤1μg/L

Display error

Lead, cadmium, arsenic: no more than ±10%or ±5.0μg/L(≤50μg/L);

Mercury: No more than ±10%or ±3.0μg/L(≤30μg/L)
