Dead-stop Titrator

Shanghai Lei Magnetic Automatic Permanent Stop Titrator ZDY-500

Price：￥5680

WeChat

Brand：lei-ci
Model：ZDY-500
Inventory Status：Spot promotion/please call for consultation

Contact：: Tel：+86 010-51660436
Email：dnyc_sales@163.com

Details Documentation Related

【Main features】

● LCD display with manual and automatic titration function；

●It has polarization voltage selection, end point setting selection, detection sensitivity selection functions ；

●Current measurement score 10^-9A、10^-8A、10^-7A、10^-6A Four gears to accommodate different chemical analysis.

【Technical parameters]

model Technical parameters	ZDY-500
Titration range	（0～10）mL，（0～25）mL
Polarization voltage	30mV、50mV、100mV
Basic error	Titration endpoint control sensitivity: ±5%FS； Polarization current detection error: ±2.5% FS； Repeatability error of capacity analysis: 0.2% reading
Polarization current detection sensitivity	0.001µA、0.01µA、0.1µA、1µA
Endpoint setting	10、20、30、40、50、60、70、80、90、100µA
power supply	AC （220±22）V；（50±1）Hz
size( mm）， weight( kg）	280mm×210mm×120mm，5kg

ZDY-500 Automatic permanent stop titrator

Serial number

Name and specifications

quantity

ZDY-500 Automatic permanent stop titrator

260Type conductive electrode (bright )

JB-10 Type stirrer

Solenoid valve components ( SC5.461.049）(With 1 fastening screw)

International general power cord

9VDC,800mA DC voltage-regulated power supply

BGXP-1 Fuse tube φ5×20 0.5A

Electrode rod A Partial installation (SC8.100.249、 With 1 electrode rod lining )

Electrode rod B (SC8.100.250)

Clip part (SC5.100.045、 With 1 fastening screw )

Support seat components (SC8.022.106)

Elastic sleeve clip (SC8.214.090)

Electrode support (SC5.108.019、 With 1 fastening screw )

Capillary dropper (SC8.403.008)

Silicone rubber tube (inner diameter φ3Outer path φ6，L=500mm）

Stir beads (B620)

Instructions for use

Product Certificate

1tower

1branch

1Only

1Parts

1root

1Only

2Only

1Parts

1branch

2root

3Only

1Book

1share

Product Brochure

User Guide

Packing List

Product Sheet
