Features

◆Touch screen controller

● It adopts an ultra-large screen touch screen, which replaces the traditional button-type operation method, making it easy to operate and easy to edit. The controller operation interface is available in Chinese and English.

● It can display instant running curves, with curve summary function, and can directly view the temperature and humidity in the same time period, CO2 Changes in the three concentration curves, abnormal alarm and door opening and closing information.

● After inputting data and test conditions, the controller has a screen lock function to avoid human touch rather than normal shutdown.

● 72The hourly machine operation record query function is to facilitate users to track abnormal situations and trace historical operation information.

● Selection RS-485 Communication interface, which can design programs on the computer, monitor the experimental process and perform functions such as power switches.

CO2 Concentration control system

● Imported infrared ( IR） Sensor control

Infrared sensors are the best choice when opening the box door frequently during the experiment. Imported infrared rays selected by Yiheng (IR)Sensor pair CO2 The concentration changes are very sensitive and are not affected by other conditions inside the incubator. The measurement accuracy is high, avoiding the monitoring of traditional thermal conductivity probes. CO2 At concentration, the influence of temperature and humidity in the box on it. If the door is opened and closed after 30 seconds, you can ≤3Recover to 5% within minutes CO2 Set the concentration, even if multiple people use it, it needs to open and close the door frequently. CO2 The concentration is fast, stable and uniform.

Temperature control monitoring system

A、 Incubator box temperature control system

● Pt100 Temperature detector ensures accurate temperature in the box. The heating power can be adjusted in real time by the difference between the actual temperature in the box and the set temperature to ensure the accuracy of the actual temperature in the box. The experimental temperature can be restored within 3 minutes after the user opens and closes the door to take samples and stakes.

B、 Door temperature heating system

● The outer box door has a heating function, and the door temperature follows the box temperature and is slightly higher than the box temperature, which can effectively prevent the glass door from producing condensation water, facilitate observation of the experimental process, and avoid the possibility of microbial contamination caused by the generation of condensation water in the glass door.

C、 Ambient temperature monitoring system

● Independent ambient temperature detector, which can be automatically adjusted according to the ambient temperature changes in the experiment. CO 2 The incubator heats the system to avoid overshooting in the box.

D、 Ultra-temperature protection system

● Independent from CO 2 A backup temperature control system outside the incubator box temperature control system. When the incubator temperature control system fails, the temperature loss of control and the indoor temperature reaches the controller temperature limit setting value, the overtemperature protection system will automatically cut off the heating and alarm sound and light.

E、 Power off alarm system

● The power supply status of the incubator is detected in real time. When power is cut off or power is lost, an acoustic and optical alarm signal will be immediately issued to make the incubator safe and reliable operation without accidents.

Sterilization system

A、90℃High temperature, humidity and heat sterilization system ( RHP）

● The inner chamber (including temperature sensors, carbon dioxide concentration sensors, fans, partitions and brackets) can be thoroughly sterilized at high temperature and humidity to completely eliminate microbial contamination caused by bacteria, molds, mycoplasma and other microorganisms on cell culture, providing users with a safe experimental environment.

● Simple operation: Users only need to simply press the (sterilization start) button on the control panel. The sterilization system can thoroughly sterilize all components in the box (including temperature sensors, carbon dioxide concentration sensors, fans, partitions and brackets). The entire sterilization process takes 18 hours to ensure comprehensive and efficient sterilization.

B、 UV sterilization system ( RWP）

● The UV sterilization lamp is located on the back of the top of the box and can be sterilized regularly inside the box, effectively killing the water vapor floating bacteria in the circulating air and humidification water tray or bottom slope water tray, thereby effectively preventing contamination during cell culture.

Automatic control of circulating fan speed

● The speed of the circulating fan can be automatically controlled. When the temperature in the box is in a constant temperature state, the speed will decrease, and the circulating wind speed will be adjusted to the wind speed suitable for cell growth, avoiding the air volume during the test.

Excessive size causes volatility of the sample.

High efficiency filter

A、 Microbial high-efficiency filter

● CO 2 Air inlets are equipped with microbial high-efficiency filters for diameters ≥0.3μm The filtration efficiency of particles is as high as 99.99%, effective filtration CO 2 Bacteria and dust particles in the gas.

B、HEPA High efficiency filter (optional)

● CO 2 The gas mass in the incubator is an important indicator for measuring the cell culture environment. HEPA The high-efficiency filter can effectively filter out bacteria and dust particles in the outside air, eliminate and prevent the cross-contamination of the outside air from the incubator, and keep the incubator in a sterile state at all times. After the box door is closed for 5 minutes, the air quality in the box can quickly return to level 100 clean level. HEPA High-efficiency filters are easy to disassemble and assemble without tools.

Safety features

Data records and fault diagnosis display  (Selection )

All information is available for RS485 Download the port to the computer to save. If a fault occurs, you can retrieve information from the computer and diagnose it in time.

Wireless alarm system (No mobile phone included ) (Selection )

If the device user is not on site, when the equipment fails, the system will collect the fault signal in a timely manner and send it to the mobile phone of the designated recipient through text messages to ensure that the fault is promptly eliminated, the test is restored, and accidental losses are avoided.

Technical parameters

Note: All technical data are for the device at 25 ℃Detection in the environment.
