Product/Brand

Environmental Simulation Chamber
Shanghai Yuejin artificial climate box HQH-H250
Price:¥25800

WeChat

Brand:HENGZI
Model:HQH-H250
Inventory Status:Spot promotion/please call for consultation
Contact:
Tel:+86 010-51660436
Email:dnyc_sales@163.com
Details Documentation Related

RQX Series of intelligent artificial climate boxes

Scope of application
This product is suitable for plant growth and tissue culture, seed germination, seed cultivation, and microbial cultivation
Maintenance test; Feeding of small insects ; Water quality monitoring BOD Determination; Medicinal materials, wood,
Aging and service life test of building materials, etc., as well as lighting for other purposes, constant temperature and humidity
Special testing equipment.

Structural features
>High-precision hot and cold constant humidity equipment with lighting and humidification functions.
>Advanced microcomputer programmable technology is used to control temperature, and a variety of parameters (including temperature, humidity, and illuminance) can be set to simulate natural climate.
>The lighting uses special high-brightness fluorescent lights.
>Light touch adjustment switch, lightweight and flexible.
>A well-known brand of compressors, using fluorine-free environmentally friendly refrigerant, with high efficiency and low energy consumption.

RQX-H Type (luxury type)
>Automatic humidity control function [Humidity control range: (50 ~90)%RH Depend on temperature, heat balance internal humidification system]
>LCD screen display, adjustable control of multiple modes, easy to operate.
>Concealed defrost method, which has no effect on the temperature in the box when defrost, and can operate for a long time.


Technical parameters:

Index Model

RQX-250H

RQX-300H

RQX-400H

RQX-250

RQX-300

RQX-400

Nominal volume (L)

250

300

400

250

300

400

Temperature control range (℃)

Light: 10 ~50℃;No light 5 ~50℃

Temperature controller

LCD screen display; Key input ; 30 segments programmable

LED   Digital display; Key input ; 30 segments programmable

Temperature fluctuation (℃)

RQX-H:±0.5            RQX :±1.5

Temperature uniformity (℃)

±2

Rated power (W)

2500

3000

3500

1000

1500

2000

Lightness

12000LX   Level 6 controllable

6000LX   Level 6 controllable

refrigerant

R134a   ( Fluorine-free environmentally friendly refrigerant)

power supply

220V±10%;50Hz

Working ambient temperature (℃)

5~35℃

Working hours

continuous

Defrosting method

Concealed defrost method, which has no effect on the temperature in the box when defrost, and can operate for a long time

When the continuous working time is not less than 180 hours, the machine will be shut down and defrosted.

Studio size (cm)

47x46x118

49x47.5x128

56x60x120

and RQX-H Same type

and RQX-H Same type

and RQX-H Same type

External dimensions (cm)

68.5x78x181

70.5x80x19.5

77.5x92.5x185

Packing box size (cm)

77x98x199

83.4x99.8x208.7

90.9x112.3x202

net weight / Gross weight (kg)

114/148

124/158

132/178


(1) Light in the temperature range:
10℃To 50 ℃ ;  No light: 5 ℃To 50 ℃
 (2) Humidity range
40%To 95% RH

(3) Temperature uniformity

 ±2 ℃

(4) Temperature fluctuation

 ±1.5 ℃               H type: ±0.5 ℃

(5) Humidity fluctuation

 ± 5~8%RH      H type: ± 3%RH

(6) Lightness

 26000 light LX     H Type: 3-sided light 12000 LX。

(7) Illuminance adjustment grading

 6Level adjustable.
