The new generation of constant temperature and humidity chambers combines the company's many years of successful experience in box design. Based on the concept of humanized design, starting from the actual needs of customers, and trying its best to meet customer requirements in every detail to provide customers with high-quality constant temperature and humidity series products.

Features:

◆Humanized design

● The new fluorine-free design allows you to always be ahead of a healthy life.

● Multi-stage programmable PID Controller, using TMHM Balanced temperature and humidity control method, precise fluctuations are small.

● It adopts imported 304 mirror stainless steel inner liner, with four corner semi-arc transitions, and the shelf bracket can be loaded and unloaded freely, making it easy to clean the box.

◆Quality assurance

● The parameters set by the user can be automatically stored in the event of a sudden power outage, and the original setting program will be run after power is turned on.

● International brand compressors and circulating fans, environmentally friendly refrigerant ( R134a） High efficiency, low energy consumption, and promote energy conservation.

● Unique air duct circulation system to ensure uniform room temperature and humidity, diameter Φ25mm Test holes for easy operation and testing.

◆Safety features

● Independent temperature limit alarm system, the operation will be automatically interrupted if the temperature exceeds the limit, and the sound and light alarm prompts the operator to ensure that the experiment is safe and accidental.

● High temperature, low temperature and overtemperature alarms, compressor overheating, overcurrent, overload protection, fan overheating protection, water shortage protection, etc.

◆Convenient data processing (optional)

● It can be connected to the printer or 485 communication interface, display it with a computer, and print the temperature, humidity and time curves, providing a strong guarantee for the storage and playback of the test process.

◆Programmable touch screen controller

● It adopts an ultra-large screen touch screen, making the screen operation simple and program editing easy.

● The controller operation interface is available in Chinese and English, and the real-time operation curve can be displayed on the screen.

● It has a capacity of 100 sets of programs with a 999 cycle step, and the maximum value is set to 99 hours and 59 minutes per period.

● After inputting data and test conditions, the controller has a screen lock function to avoid shutdown due to human touch.

● have P.I.D Automatic calculation function can immediately correct the temperature and humidity changes, making the temperature and humidity control more accurate and stable.

● have RS-232 or RS-485 Communication interface, which can design programs on the computer, monitor the test process and perform functions such as power switches. (Optional)

Technical parameters

Note:

1、BPS-50CH、BPS-100CH、BPS-250CH No refrigeration function.

2、BPS-100CB、BPS-250CB After receiving the order, the delivery time is 15 days.

3、BPS-500/800/1000Series, after receiving the order, the delivery time is 30 days.

Optional parts: (Add to 7 days for optional parts delivery)

 Note: RS485/232、Choose one of two printers
