Features:

● Vague PID The controller has accurate temperature control fluctuations and small, with timing function, the maximum time setting value is 99 hours and 59 minutes.

● The forced convection air duct system can improve temperature response speed, improve temperature uniformity and reduce temperature fluctuations.

● There is a layer of glass door on the inner layer of the box door, which is easy to observe. When the glass door is opened, the breeze circulation and heating will automatically stop, without the disadvantage of temperature overshoot.

● Mirror stainless steel inner liner, electric heating film heating method, fast heating speed, making the box evenly heated.

● Independent temperature limit alarm system, the temperature exceeds the limit will be automatically interrupted, ensuring safe operation of the experiment without accidents. (Selection )

● Can be equipped with a printer or RS485 Interface, used to connect to a printer or computer, can record changes in temperature parameters. (Selection )

◆ Automatic control of circulating fan speed

● The speed of the circulating fan can be automatically controlled. When the temperature in the box is in a constant temperature state, the speed will decrease, and the circulating wind speed will be adjusted to a wind speed suitable for cell growth, avoiding the volatility of the sample due to excessive air volume during the test.

◆ Multi-segment programmable controller (optional)

● Multi-stage LCD programmable controller, multiple parameters are displayed on one screen, and menu-style operation interface can simplify complex test processes and truly realize automatic control and operation.

● Multi-stage temperature, circulating wind speed, time and heating rate can be set and programmed at the same time, and gradient control of temperature rise can be performed, and functions such as slow heating from the initial temperature in the box can be preset. Functions such as automatic power-on, standby and shutdown can also be preset.

● 7 segments and 63 steps can be preset, 9 steps per segment, and 1 time per segment ～9959 minutes at hour.

◆ Safety features

● Independent temperature limit alarm system, and sound and light alarm reminds the operator to ensure safe operation without accidents. (Optional)

● High or low temperature and overtemperature alarm.

◆ UV sterilization system (optional)

● The inside of the box can be disinfected regularly, which can effectively kill the floating bacteria in the circulating air in the box, thereby effectively preventing contamination during cell culture.

Technical parameters:

※Performance parameter test under no load conditions is: ambient temperature 20 ℃，Ambient humidity 50% RH

Note:

“B” Export type electric heating incubator

DHP-9012, DHP-9032 There is observation window without glass door

Optional purchase: (Increase the delivery time of optional parts for 7 days )

Note: RS485、 Choose one of two printers
