2

304Stainless steel material, self-expanding sealing ring

3

Automatically controlled sterilization cycle program, pressure safety interlocking interactive device

4

Digital window LCD display working status, double-scale reading pressure gauge

5

Overpressure self-leakage 0.145-0.24 Mpa

6

Sterilization temperature optional setting range 50 ℃-134℃

7

Adjustable sterilization time setting range 0-99 h

8

With water cut protection device

9

Automatic shutdown after sterilization is finished

10

Printing function can be added (extra fee)

11

Volume: 120 liters, power supply voltage: 380 V， Power: 7.5 KW

12

Sterilization chamber size: φ400*960（mm）

13

Packaging size: 1320 *632*1600（mm）， Net instrument size: 1220 *620*1540（mm）

14

Gross weight: 230 KG， Thickened carton

15

Have a nationally stipulated special equipment pressure vessel certificate

Pressure temperature switch

High and low pressure

1indivual

Solid-state relay

440V  40A

3indivual

Fuse

380V  16A

3indivual

Electric heating tube

2500W

3branch

Spring safety valve

0.217-0.24Mpa

2indivual

Steam discharge valve

1indivual

Pressure gauge

2indivual

Silicone sealing ring

1indivual

Pressure steam sterilizer

1tower

Instructions for use

1share

Quality tracking card

1share

Pressure vessel monitoring certificate

2share

Net basket

2Only
