RUQingdao Haier Haier Ultra-clean workbench HCB-1300V(S)
Price：￥25000
Laboratory/Medical Field
Integrated suppliers of equipment, reagents, and consumables
Double single side /Single double-sided purification workbench
Scope of application
Widely applicable to medical and health care, pharmaceuticals, chemical experiments, electronics, national defense, precision instruments, instruments
Table of contents and other industries.
Structural features
>Horizontal flow characteristics:
>Vertical manifold, quasi-closed tabletop, can effectively prevent external airflow from infiltration and irritation of the human body by operating odor.
>The ultra-thin partition-free filter is used to minimize the size of the static pressure box, and is equipped with stainless steel countertops and glass side baffles, making the entire studio look spacious and bright.
>It adopts a high-efficiency iron shell centrifugal fan, with stable speed and low noise.
>The mobile door adopts a spring-type sliding door, which can be positioned arbitrarily within the specified range.
>The damper made of aluminum alloy can adjust the pre-filtered air inlet volume at will.
Technical parameters:
Index Model | S.SW-CJ-1F/1FD | S.SW-CJ-2F/2FD | S.VS-1300U | S.VS-840U |
| |||
Cleanliness | 100 class@ ≥ 0.5μm（ United States Federation 209 E） | |||||||
Number of colonies | ≤ 0.5 indivual / Dish Time ( Φ90mm Culture dish) | |||||||
Average wind speed | 0.3~0.6m/s（ Recommended wind speed 0.5 m/s） | |||||||
noise | ≤ 62dB(A) | |||||||
Vibration half peak value | ≤ 0.5μm | |||||||
Illumination | ≥ 300Lx | |||||||
power supply | AC Single phase 220 V/50Hz | |||||||
Maximum power consumption | 0.4KW | 0.8KW | 0.8KW | 0.4KW | ||||
net weight /Gross weight | 80/130kg | 130/210kg | 130/210kg | 80/130kg | ||||
W1: Workspace width | 87 | 136 | 112 | 68 | ||||
D1: Workspace depth | 70 | 70 | 65 | 65 | ||||
H1: Workspace height | 52 | 52 | 72 | 57 | ||||
W: Width device shape | 99 | 148 | 130 | 84 | ||||
D: Depth of device | 76 | 76 | 76 | 82.5 | ||||
H: High device shape | 162 | 162 | 175 | 143 | ||||
Packing box size ( cm） | 113x87x180 | 162x87x180 | 144x87x192 |
| ||||
High-efficiency filter specifications and quantity | 820x600x60x ① | 610x610x69x ② | 610x610x69x ② | 760x61x50x ① | ||||
Fluorescent lamp / UV lamp specifications and quantity | 20Wx ① /20Wx ① | 20Wx ② /20Wx ② | 20Wx ② /20Wx ② | 18Wx ① /20Wx ① | ||||
Number of people applicable | 1F: Single person double face； 1 FD: Single person single side | 2F: Double face； 2 FD: Double single side | Double single side | Single person single side | ||||
Price：￥25000
Price：￥18800
Price：￥20000
Price：￥15300
Price：￥13300
