1

Adopt a shifted quick-opening structure, making the pot cover open and lock safe, reliable, flexible and lightweight

2

With water-breaking protection device, maximum working pressure of 0.142 Mpa

3

Self-expanding sealing ring, electric heating method

4

Pressure interlocking cover device, double scale reading pressure gauge

5

Can preset fixing procedures to sterilize sterilized items；

6

Can store the last sterilization program for easy secondary operation

7

It has the functions of lower discharge of cold air and lower drainage

8

Digital display screen and indicator light can display the set sterilization work dynamics and operation function prompts

9

All stainless steel, cylinder thickness: 2 mm

10

Adopt a safety structure that interacts with electronics and machinery, so that the interlocking device automatically locks the pot lid when there is pressure in the pot to ensure safe operation of the user

11

Implement microcomputer control system, adopt“ LED” Digital display running work program, automatically shut down after sterilization is completed (alarm).

12

The shell conforms to the humanized design concept, and the material is made of high-quality high-temperature-resistant engineering plastic, which avoids the hidden danger of hotness of the shell of the traditional portable sterilizer.

13

With castors at the bottom, easy to move

14

Product compliant GB/T 150《 Pressure Vessel Design and Manufacturing

15

Design service life ≥10Year

16

Power: 2 KW， Volume: 24 L

17

Temperature setting range 50 ℃-126℃，Time setting range 0-99 h

18

Operating voltage: 220 V； Frequency: 50 Hz

19

Gross weight: 29 kg, Net weight: 27 Kg

20

Inner liner diameter *Height: 269 *320 mm

21

Outer packaging size (length *Width *High): 540 *500*900 mm, Net instrument size: 440 *484*815mm

22

Have a nationally stipulated pressure vessel certificate

Configuration list

Serial number

name

Specification

quantity

1

Computer board and silicone

1set

2

Circuit breaker switch

250V  16A

1indivual

3

Water level float ball

1indivual

4

Electric heating tube

2000W

1root

5

Fully open safety valve

0.142-0.165Mpa

1indivual

6

Steam discharge valve

1indivual

7

Pressure gauge

1indivual

8

Silicone sealing ring

1indivual

9

Solid-state relay

1indivual

10

Inner liner

1indivual

Packing list

Name

Specifications and models

quantity

Remark

Portable high-pressure steam sterilizer

DSX-24L-I

1

Product quality tracking card

——

1

Product Certificate

——

1
